Latest Welder Cutting Fiber Machine Double Wobble Robot Fiber Laser Welding Machine for Metal

Basic Info.

Model NO.	LMH1000
Laser Wave Length	1070nm
Laser Pulse Width	Pulsed Xenon Lamp
Product Name	Handheld Type Fiber Laser Welding Machine
Transport Package	Plywood Box
Specification	138*86*146cm
Trademark	Laser Max
Origin	China
Production Capacity	100 Sets/Months

Product Description

Latest welder cutting fiber machine double wobble robot fiber laser welding machine for metal

Dual-axis oscillatingHandheld laser welding machine
Double pendulum handheld laser welding machine, using qilin dual-axis pendulum handheld welding head and qilin control system, with six kinds of spot welding, external LCD screen precision display, built-in drive control system circuit, with the advantages of simple operation, beautiful welding seam, fast welding speed, no consumables, can achieve any angle of the workpiece, suitable for a variety of complex welding seam, spot welding of various devices, while integrated cutting function, can meet different production needs.

Product Features

1. the control system is easy to operate, the laser beam quality is good, the welding speed is fast, the weld isfirm and beautiful, the weld joint is smooth, the weld is flat and without porosity.2. Handheld welding head, flexible and convenient, longer welding distance. Welding influence area is small,will not lead to deformation, blackening, traces on the back of the problem, and the welding depth is large,solid welding and full melting.3. Applicable to a variety of complex welding seams, overcome the limitations of the table, you can achieve anypart of any angle of the workpiece welding.4. Integrated intelligent management of welding system, built-in drive control system circuit, high photoelectricconversion rate, low energy consumption, long-term use can save a lot of processing costs.5. The only welding head in the market with 6 light spot modes, fully covering different light spots of point, line,circle, double circle, triangle and eight.
Variety of welding products
Small focal spot, high power density, can weld high melting point, high strength metals and alloy materials, suitable for a variety of complex welds, welding of various devices, welding quality is more excellent, small deformation, high melting depth.

Welding SamplesProduct Parameters

Machine model		Hand-held fiber laser welding machine
Laser source		Raycus/JPT/MAX/IPG
Laser power		1000W,1500W,2000W
Laser wave length		1070 NM
Welding speed range		0~120 mm/s
Laser pulse width		0.1-20ms
Cooling chiller		Industrial water chiller
Working environment temperature range		15~35 ºC
Humidity range of working environment		< 70% No condensation
Welding thickness recommendations		0.5-3mm
Welding gap requirements		≤0.5mm
working voltage		220 V
Weight		270kg

Product DetailsProduct Real Show
