Class One Full Sealing Microelectronic Micrometer Laser Welding Marking System for Tiny Plastic Metal Component with CCD Visualization

Basic Info.

Model NO.	CKD-SMLA-3/3/15/20/30/50/60/100, V22.06
Applicable Material	Metal
Cooling System	Air Cooling
Technical Class	Pulse Laser
Laser Wavelength	Fiber Laser
Laser Classification	Solid Laser
Type	Optical Fiber Laser Marking Machine
Marking Method	Scanning Marking
Material	Metal and Some Non-Metal
Shipping Date	8-15 Work Days After Payment
Marking Scope	100*100mm
Laser Power	Optional: 20/30/50/60/100W
Transport Package	Wooden Box
Specification	Class One, CE
Trademark	CKD LASER
Origin	Shenzhen, China
HS Code	8486204900
Production Capacity	200 Set/Month

Packaging & Delivery

Package Size 135.00cm * 100.00cm * 195.00cm Package Gross Weight 260.000kg

Product Description

CKD-SMLA V22.06 is a comprehensive laser system, including kinds of functions to choose, the finally function needs to adapt user's application by strengthen or weaken some functions.It can mark, weld, cut and clean. Functions including vision location, background display, vision location, 3D dynamic focusing and so on. Mainly used for tiny, easily broken material and for highly-demand that must be clearly enough to timely monitor laser working trace for those sophisticated components.Compared the past vision location system, CKD-SMLA V22.06 is:

1. Much highly integration: no need installation, no off-set potential risk, free extra light.
2. Much faster: when fast moving, without delay of the background display. Much quickly identify, capture and calibration of marking contents.
3. Higher degree of automation: free the operator debugging time.
4. Contactless and precision laser marking, reduces accidental damage to materials.

APPLICATION EXAMPLES:Much easier operation software. Once the temple is set, the machine can enter into operator mode, don't worry about unexpected changes in processing contents.OPERATION EXAMPLE:Mark tiny words on 0.5mm diameter's wafer on PCB circuit board:

1. Set: Put the material in marking scope and set marking contents and parameters.
2. Point: The machine will clearly show the material's image on computer. Box choose any location on wafer, the set content will timely on the pointed location.
3. Mark: The machine will quickly recognize the location, automatically calibration the direction and laser mark.

Fast show the material with delay no matter how you change the location of material, 12,000,000 HD pixel clearly display.AUTOMATICALLY DIRECTION CALIBRATION:Tiny material is hard to out direction by hands one by one, waste time even by a robot arm.For CKD-SMLA V22.06, just keep the tiny material in recognizing scope, not matter what directions, the material will mark contents in right directions you set.All operation tools are integrated on right side together, seamless built the keyboard and mouse in the drawer.We supply professional OD4+ 200-450 & 800-2000nm laser protective glass on the slide door, the user also can choose an acrylic of they like wear laser protective goggles.CKD-SMLA V22.06 has a very small noise, the user can connect a smoke purifier at the back the machine. It is fully considered for human health and environment protection.CONFIGURATION:

Type	Laser power	Laser wavelength	Laser focus	Optional system / function
CKD-SMLA-3	3W	355nm	Motorized-focusAuto-focus	* Vision location* Background display* Lighting system* 3D dynamic* Marking* Welding* Cutting* Rotary*Adsorption function* Smoke purifier* Other customized function
CKD-SMLA-5	5W
CKD-SMLA-15	15W
CKD-SMLA-20	20W	1064nm
CKD-SMLA-30	30W
CKD-SMLA-50	50W
CKD-SMLA-60	60W
CKD-SMLA-100	100W
